Plate Ice Machine P10A (5T/D)

NO.P50A

Plate Ice Machine P10A (5T/D)

NO.P50A

Product Description Technical Parameters

Application field:
Food processing
Fishery processing
Meat processing
Medical scientific research
Supermarket and Logistic
Dye chemical industry
Cold accumulation project
Product feature:
Stainless steel one plate with two ice freezing surface , full production
The ice thickness 3-20mm adjustable , and fulfill to the different application
Special fow type plate design, compared with smiliar product , the refrigeration efficient is higher and more energy save.
Adapt hot refrigerant gas for ice doffing , ice doffing faster and without secondary polluation.
The evaporator is open type design, the freezing plate surface , water spray span, water channel is easy to clean.
The part contact with ice is stainless steel , it fully conforms to the certification requirement of HACCP.
Special refrigeration system design, adapted to different working condition and working stable.
Simplified structure , the move part is less and matainance is easy
The machine adapts the hot dipped galvanized steel welding structure, corrosion resistance, long service life
Full-automatic control

Working condition:
Power supply: full electric system complying with the general international standard
Stardard working condition of ice making: water supply temperature 20℃, ambient temperature 33℃
The applicable working condition: water supply temperature 0~35℃, ambient temperature 5~40℃
Refrigerant: R404A、R507A
Performance Parameter:
Capacity of ice making:1000kg/d
Evaporating temp.: -18℃, condensing temp.: 43℃
Compressor model: SP-2H0600, quantity of compressor:1 set
Compressor refrigeration capacity:7.3kw, compressor motor:6HP
COP:1.97 kW /kW, power:3.7 kW
Cylinder head air fan:0.15kw
Cooling water pump:0.25kw, cooling air fan:0.2kw
Reducer:0.37kw
Running electricity consumption:4.67kw, installation power:5.47kw
Ice making electricity consumption: 102.82kW.h/t,, ice making water consumption: 42.08l/h
Ice output dimension: 1081*135mm
Weight:1200kg
Overall dimension: L1590*W1070*H1775mm
(due to technical innovation, the parameter above will be some change, please contact our sales department if needful)
